The filter bagis a type of stacked filtration,where the filter layer forms a three-dimensional,loose,porous structure made of fibers.The structure is denseron the inside and gradually becomes looser on the outside,creating a gradient filter that improves liquid throughput and impurity holding capacity.The needle-punched felt surface is treated with processes such as singeing and calendaring to prevent fiber loss and eliminate the risk of secondary contamination.
| Material | Max.Operating Temperature(°C) | Accuracy |
| PP | 90 |
0.5-600um |
| PE | 150 | |
| NMO | 190 | |
| PTFE | 300 |
| Model | size | Max.Flow Rate(m3/h) | Filtration Area(m²) | Max.Differential Pressure(Mpa) | Suggested Cleaning/Replacement Pressure Differential(Mpa) |
| 1# | 0180x450mm | 20 | 0.24 | 2.5 bar | 0.8-1.5 bar |
| 2# | ②180x810mm | 40 | 0.48 | ||
| 3# | ②108×230mm | 6 | 0.09 | ||
| 4# | ⑦108x380mm | 12 | 0.16 | ||
| 5# | ⑦152x520mm | 12 | 0.18 |
